PEAR is a plug connector with a jack connection, which can be used to connect external devices such as a pear push button. If these devices are triggered, PEAR transmits an alarm that is sent to the carephone system. External devices can be controlled in specific situations via two relay outputs.
PEAR is easy to surface- or flush-mount. It is also easy to attach external devices.
Connection of external devices via
a jack connection
Size: 85 x 85 x 30 (L x W x H)
Surface mounting with frame or direct
onto flush-mounted socket outlet
Screw terminal strip so that external devices can easily be connected
Integrated LED for status display
Integrated radio receiver and transmitter
Eight radio transmitter channels can be set
Two inputs and two outputs
Can be configured via jumper or the
WIOR programmer
Powered through battery (2 x AAA) or external network component (10-24 V DC)
Battery status monitoring
Transmission path monitoring
